The table below clearly presents the key parameters of 1/8" to 36" SCH 10 carbon steel pipes:
|
Pipe Size (NPS) |
OD (mm) |
OD (inch) |
kg/m |
lb/ft |
Thickness (mm) |
Thickness (inch) |
|
1/8² (NPS 6) |
10.3 |
0.41 |
0.28 |
0.19 |
1.24 |
0.049 |
|
1/4² (NPS 8) |
13.7 |
0.54 |
0.49 |
0.33 |
1.65 |
0.065 |
|
3/8² (NPS 10) |
17.1 |
0.68 |
0.63 |
0.42 |
1.65 |
0.065 |
|
1/2² (NPS 15) |
21.3 |
0.84 |
1.0 |
0.67 |
2.11 |
0.083 |
|
3/4² (NPS 20) |
26.7 |
1.05 |
1.28 |
0.86 |
2.11 |
0.083 |
|
1² (NPS 25) |
33.4 |
1.32 |
2.09 |
1.4 |
2.77 |
0.109 |
|
1-1/4² (NPS 32) |
42.2 |
1.66 |
2.7 |
1.81 |
2.77 |
0.109 |
|
1-1/2² (NPS 40) |
48.3 |
1.9 |
3.11 |
2.09 |
2.77 |
0.109 |
|
2² (NPS 50) |
60.3 |
2.375 |
3.93 |
2.64 |
2.77 |
0.109 |
|
2-1/2² (NPS 65) |
73.0 |
2.875 |
5.26 |
3.53 |
3.05 |
0.12 |
|
3² (NPS 80) |
88.9 |
3.5 |
6.45 |
4.33 |
3.05 |
0.12 |
|
3-1/2² (NPS 90) |
101.6 |
4.0 |
7.4 |
4.97 |
3.05 |
0.12 |
|
4² (NPS 100) |
114.3 |
4.5 |
8.36 |
5.61 |
3.05 |
0.12 |
|
5² (NPS 125) |
141.3 |
5.563 |
11.57 |
7.77 |
3.4 |
0.134 |
|
6² (NPS 150) |
168.3 |
6.625 |
13.84 |
9.29 |
3.4 |
0.134 |
|
8² (NPS 200) |
219.1 |
8.625 |
19.96 |
13.4 |
3.76 |
0.148 |
|
10² (NPS 250) |
273.0 |
10.75 |
27.78 |
18.65 |
4.19 |
0.165 |
|
12² (NPS 300) |
323.8 |
12.75 |
36.0 |
24.17 |
4.57 |
0.18 |
|
14² (NPS 350) |
355.6 |
14 |
54.69 |
36.71 |
6.35 |
0.25 |
|
16² (NPS 400) |
406.4 |
16 |
62.64 |
42.05 |
6.35 |
0.25 |
|
18² (NPS 450) |
457.0 |
18 |
70.57 |
47.39 |
6.35 |
0.25 |
|
20² (NPS 500) |
508.0 |
20 |
78.55 |
52.73 |
6.35 |
0.25 |
|
22² (NPS 550) |
559.0 |
22 |
86.54 |
58.07 |
6.35 |
0.25 |
|
24² (NPS 600) |
610.0 |
24 |
94.53 |
63.41 |
6.35 |
0.25 |
|
26² (NPS 650) |
660.0 |
26 |
127.36 |
85.6 |
7.92 |
0.312 |
|
28² (NPS 700) |
711.0 |
28 |
137.32 |
92.26 |
7.92 |
0.312 |
|
30² (NPS 750) |
762.0 |
30 |
147.28 |
98.93 |
7.92 |
0.312 |
|
32² (NPS 800) |
813.0 |
32 |
157.24 |
105.59 |
7.92 |
0.312 |
|
34² (NPS 850) |
864.0 |
34 |
167.2 |
112.25 |
7.92 |
0.312 |
|
36² (NPS 900) |
914.0 |
36 |
176.96 |
118.92 |
7.92 |
0.312 |
As can be seen from the table data, the key advantages of SCH 10 pipes are reflected in three dimensions:
1. Lightweight and economical:
Thin-walled structures (e.g., DN25 pipe: 2.77mm thick, weighing 2.09kg/m) reduce transportation and installation costs by more than 30%. The weight reduction effect is even more significant for large-diameter pipes (DN600 only 94.53kg/m).
2. Scientific wall thickness gradient:
The wall thickness increases in a stepped manner with increasing pipe diameter (DN250→4.19mm / DN350→6.35mm / DN750→7.92mm), maintaining a stable structure while withstanding design pressure (typically ≤2.5MPa), simplifying the selection process.
3. Precise operating condition adaptation:
Based on optimized pressure parameters, it is particularly suitable for:
HVAC systems (chilled water/HVAC)
Low-pressure fire protection piping networks
Atmospheric pressure chemical media transportation
Steam systems with operating pressure ≤1.6MPa (requires STPT material)
Meets the compliance requirements for non-corrosive fluid pipelines in the food/pharmaceutical industries.
Read more：Schedule 10 carbon steel pipe
