ASTM Structural Steel Plates

ASTM Structural Steel Plates

A36 Steel Plates

A low-carbon steel with excellent fabrication properties. This grade is commonly utilized for general fabrication and structural purposes such as steel building components. Due to its wide variety of applications, Chapel Steel carries a vast inventory of this grade.


Item : Carbon Structural Steel Plates - ASTM A36
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm

Inquire Now
  • Description
  • Specification
  • Standard
  • Process
  • Packing
  • Images

A36 Steel Plates


A low-carbon steel with excellent fabrication properties. This grade is commonly utilized for general fabrication and structural purposes such as steel building components. Due to its wide variety of applications, Chapel Steel carries a vast inventory of this grade.


Item : Carbon Structural Steel Plates - ASTM A36
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm


A36 structural Plates Chemical Composition

Grade C Si Mn P S
ASTM A36 0.25 max. 0.4 max. 0.8-1.2 0.035 max. 0.035 max.

A36 High tensile Plates Mechanical Properties

Tensile strength, kis [MPa] Yield strength, min, kis [MPa] Elongation in 8 in. [200 mm], min, % Elongation in 2 in. [50 mm], min, %
58-80 [400-550] 36 [250] 20 23

A36 Steel Plates Equivalent grades
EN USA GB BS JIS ISO IS
Fe360D2, S235J2G4 A36 Q235D 40EE SM 400 A Fe 360B IS 226


A36 Plate Processing
Cutting
Forming Drilling/ Machining
Grinding
Testing


A36 Steel Plates
